Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style
Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style
Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style
Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style
Roll over image to zoom in Click on image to zoom
Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old StyleOil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old StyleOil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old StyleOil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style

Oil Bath Bearing 10-1/2" (262 mm) for Axles Square 1 1/2 inch for Case 770 Old Style

ABD EQUIPMENT & PARTS LLCSKU: 131-000129
Price:
$296.49

Description

All-in-One Oil Bath Bearing 10-1/2" (262mm) for 1-1/2" Square & 1-5/8" Round Axles - Replaces Fragile Parts in Case IH 596, 770 Old Style

Product Description:

Robust Single-Piece Oil Bath Bearing Assembly - Eliminates Need for Multiple Components

This 10-1/2" (262mm) oil bath bearing assembly is crafted to replace traditional fragile components in agricultural machinery, specifically for Case IH models 596 and 770. It serves as a direct replacement for the ball bearing ST740B, support tube #549971R1, and two spools #549977R1. Designed to fit both 1-1/2" square and 1-5/8" round axles, this single-piece unit enhances durability and simplifies installation, streamlining maintenance and improving reliability.

Key Features:

  • Fit: Designed for 1-1/2" square or 1-5/8" round axles.
  • Efficiency: Integrates all necessary components into one durable assembly.
  • Replaces: Eliminates the need for separate ball bearings, support tubes, and spools.
  • Protection: Features axial oil protection to enhance bearing longevity and performance.
  • Measurements: 10-1/2 inch diameter with a disc support hole spacing of 140mm, suitable for disc spacings of 262/270mm.
  • Durability: Built to withstand the rigorous demands of agricultural use.


Field Details
Interchange Numbers Case IH 596, 770
Condition New
Diameter 10-1/2" (262mm)
Axle Compatibility 1-1/2" Square, 1-5/8" Round
Components Replaced Ball Bearing ST740B, Support Tube #549971R1, 2 Spools #549977R1
Brand Baldan
Product Category Oil Bath Bearings for Agricultural Machinery
Measurements Disc Support Hole Spacing: 140mm, Disc Spacing: 262/270mm
Fit To Case IH, and compatible equipment
Other Product Category Agricultural Machinery

Keywords: , Oil Bath Bearing Assembly for case 770 ,OIL BATH 10 1/2", Bearing Assembly for Case 770, B-000596, Spool #549977R1, Support Tube #549971R1, Ball Bearing - 55.58mm ID #ST740B, Ball Bearing ST740B,FD211RB,ST740B (CNH),ST740ANH), ST740BIMP, FD211TTRBAN/3AS, FD211RBA, AFD211RBA, FD211RB-IMP, ST740B-IMP, DHU2-3/16R211, FD211RBIMP,Case IH Disc Harrow 370, Case IH Disc Harrow 501, Case IH Disc Harrow 596, Case IH Disc Harrow 770, Case IH Disc Harrow 790,B-000596 Oil Bath Bearing Assembly for Case 770,
